Tech In Plain Sight: Magsafe, And How To Roll Your Own

February 25, 2025 by 6 Comments

Apple likes magnets. They started out with magnetic laptop chargers and then graduated to a system that magnetically holds the phone, charges it, and can facilitate communication between the phone and a charger or other device. Even if you are like me and have no Apple devices, you can retrofit other phones to use Magsafe accessories. In fact, with a little work, you can build your own devices. Regardless, the technology is a clever and simple hack, and we are just a little sorry we didn’t think of it.

Terms

Using a magnet to attach a phone isn’t a new idea. But, historically, the phone had either a metal back or an adhesive metal plate attached that would stick to the magnet. This wouldn’t necessarily help with charging, but was perfectly fine for holding the device. The problem is, it is hard to wirelessly charge the phone through the metal.

Magsafe can do several different things. Obviously, it can attach the phone magnetically. However, since it is a ring shape, you can still have a charging coil in the middle of the ring. Better still, the Magsafe system will align the phone and charger with a satisfying click when you put them together.

Continue reading “Tech In Plain Sight: Magsafe, And How To Roll Your Own” →

To Test A (Smart) LED

February 24, 2025 by 14 Comments

Adding LEDs to a project used to be enough to make it cool. But these days, you need arrays of addressable multi-color LEDs, and that typically means WS2812B or something similar. The problem is that while it was pretty easy to test garden-variety LEDs, these devices can be a bit harder to troubleshoot. [Gokux] has the answer, as you can see in the video below.

Testing these was especially important to [Gokux] because they usually swipe the modules from other modules or LED strips. The little fixture sends the correct pulses to push the LED through several colors when you hold it down to the pads.

However, what if the LED is blinking but not totally right? How can you tell? Easy, there’s a reference LED that changes colors in sync with the device under test. So, if the LEDs match, you have a winner. If not… well, it’s time to desolder another donor LED.

This is one of those projects that you probably should have thought of, but also probably didn’t. While the tester here uses a Xiao microcontroller, any processor that can drive the LEDs would be easy to use. We’d be tempted to breadboard the tester, but you’d need a way to make contact with the LED. Maybe some foil tape would do the trick. Or pogo pins.

Continue reading “To Test A (Smart) LED” →

Line Power With No Transformer

February 24, 2025 by 43 Comments

Normally, when you want a low DC voltage from the AC line, you think about using a transformer of some kind. [RCD66] noticed that an AC monitor meter must have some sort of power supply but had no transformers in sight. That led to an exploration of how those work and how you can use them, too. You can watch the work in the video below.

Sensibly, there is a transformer in the test setup — an isolation transformer to make it safe to probe the circuit. But there’s no transformer providing voltage changes. Isolation is important even if you are taking apart something commercial that might be trasformerless.

The circuit is simple enough: it uses a capacitor, a resistor, and a pair of diodes (one of them a zener diode). He uses this basic circuit to drive simple regulators with input and output filter capacitors. We’ve seen many variations on this design over the years.

You can’t draw a lot of power through this arrangement. But sometimes it is all you need. However, this is pretty dangerous, as we’ve discussed before. Be sure you understand exactly what the risks are before you decide to build something like this.

Continue reading “Line Power With No Transformer” →

Unhacked Mattress Phones Home

February 24, 2025 by 29 Comments

[Dylan] has a fancy bed that can be set to any temperature. Apparently this set him back about $2,000, it only works if it has Internet, and the bed wants $19 a month for anything beyond basic features. Unsurprisingly, [Dylan] decided to try to hack the mattress firmware and share what he learned with us.

Oddly enough, it was easy to just ask the update URL for the firmware and download it. Inside, it turned out there was a mechanism for “eng@eightsleep.com” to remotely SSH into any bed and — well — do just about anything. You may wonder why anyone wants to gain control of your bed. But if you are on the network, this could be a perfect place to launch an attack on the network and beyond.

Of course, they can also figure out when you sleep, if you sleep alone or not, and, of course, when no one is in the bed. But if those things bother you, maybe don’t get an Internet-connected bed.

Oddly enough, the last time we saw a bed hack, it was from [Dillan], not [Dylan]. Just because you don’t want Big Sleep to know when you are in bed doesn’t mean it isn’t useful for your private purposes.

Learn Assembly The FFmpeg Way

February 23, 2025 by 26 Comments

You want to learn assembly language. After all, understanding assembly unlocks the ability to understand what compilers are doing and it is especially important for time-critical code. But most tutorials are — well — boring. So you can print “Hello World” super fast. Who cares?

But decoding video data is something where assembly can really pay off, so why not study a real project like FFmpeg to see how they do things? Sounds like a pain, but thanks to the FFmpeg asm-lessons repository, it’s actually quite accessible.

According to the repo, you should already understand C — especially C pointers. They also expect you to understand some basic mathematics. Most of the FFmpeg code that uses assembly uses the single instruction multiple data (SIMD) opcodes. This allows you to do something like “add 5 to these 200 data items” very quickly compared to looping 200 times.

Continue reading “Learn Assembly The FFmpeg Way” →

Over The Counter Glucose Monitor Dissected

February 23, 2025 by 33 Comments

If you deal with diabetes, you probably know how to prick your finger and use a little meter to read your glucose levels. The meters get better and better which mostly means they take less blood, so you don’t have to lacerate your finger so severely. Even so, taking your blood several times a day is hard on your fingertips. Continuous monitoring is available, but — until recently — required a prescription and was fairly expensive. [Andy] noticed the recent introduction of a relatively inexpensive over-the-counter sensor, the Stelo CGM. Of course, he had to find out what was inside, and thanks to him, you can see it, too.

If you haven’t used a continuous glucose monitor (CGM), there is still a prick involved, but it is once every two weeks or so and occurs in the back of your arm. A spring drives a needle into your flesh and retracts. However, it leaves behind a little catheter. The other end of the catheter is in an adhesive-backed module that stays put. It sounds a little uncomfortable, but normally, it is hardly noticeable, and even if it is, it is much better than sticking your finger repeatedly to draw out a bunch of blood.

Continue reading “Over The Counter Glucose Monitor Dissected” →

Retrotectacular: Ham Radio As It Was

February 21, 2025 by 22 Comments

We hear a lot about how ham radio isn’t what it used to be. But what was it like? Well, the ARRL’s film “The Ham’s Wide World” shows a snapshot of the radio hobby in the 1960s, which you can watch below. The narrator is no other than the famous ham [Arthur Godfrey] and also features fellow ham and U.S. Senator [Barry Goldwater]. But the real stars of the show are all the vintage gear: Heathkit, Swan, and a very oddly placed Drake.

The story starts with a QSO between a Mexican grocer and a U.S. teenager. But it quickly turns to a Field Day event. Since the film is from the ARRL, the terminology and explanations make sense. You’ll hear real Morse code and accurate ham lingo.

Continue reading “Retrotectacular: Ham Radio As It Was” →
